Lock, load, and dominate your next-gen desktop gaming setup with military-grade resilience. The ASUS TUF Gaming Radeon™ RX 7600 XT OC Edition is an elite, high-performance graphics card built to push high-frame rates at 1080p and 1440p resolutions. Powered by the cutting-edge AMD RDNA™ 3 architecture and packed with a massive 16GB of high-speed video memory, this card easily handles the high VRAM demands of modern AAA gaming titles, heavy streaming workloads, and intensive content creation tasks. Equipped with an all-metal exoskeleton and a robust triple Axial-tech cooling design, it delivers exceptional thermal efficiency with whisper-quiet operation under heavy gaming stress.

Key Features

➔ Future-Ready 16GB GDDR6 VRAM: Loaded with double the standard buffer size to ensure textures load fluidly, eliminating frame stutters in demanding open-world maps and texture-heavy environments.

➔ Factory Overclocked Core Frequency: Out of the box engine clock speeds tuned up to 2830 MHz (Boost Clock) in OC mode to safely extract maximum processing power.

➔ Advanced Upgraded Axial-Tech Fans: Three heavy-duty fans run on durable dual-ball bearings, facilitating 24% more airflow through the massive heatsink to keep core temperatures chilled.

➔ Intellectual 0dB Silent Gaming: Side fans spin counter-clockwise to drastically eliminate turbulence. All three fans come to a complete standstill when internal GPU temps drop below 55°C for dead-silent desktop workflows.

➔ Military-Grade 20K Capacitors: Built with a highly resilient power-delivery circuit array rated to withstand 20,000 hours at 105°C, providing robust ripple tolerance and long-term voltage stability.

➔ Rigid Protective Aluminum Exoskeleton: A premium structural aluminum shroud and a vented metal backplate prevent PCB flexing, redirecting structural stress while improving passive airflow pathways.

➔ Aura Sync ARGB Illumination: Features customizable color accents on the outer shroud, allowing seamless hardware synchronization across your entire PC building layout.

Technical Specifications

Component / Feature	Specification
Graphics Engine	➔ AMD Radeon™ RX 7600 XT (Navi 33 XT / RDNA 3)
Stream Processors	➔ 2048 Units
Video Memory Array	➔ 16GB GDDR6 SDRAM
Engine Clock (OC Mode)	➔ Boost Clock: Up to 2830 MHz / Game Clock: Up to 2559 MHz
Engine Clock (Default Mode)	➔ Boost Clock: Up to 2810 MHz / Game Clock: Up to 2539 MHz
Memory Interface Bus	➔ 128-bit
Memory Speed Rate	➔ 18 Gbps
Bus Standard Interface	➔ PCI Express 4.0
Digital Max Resolution	➔ 7680 x 4320 Ultra HD
Multi-Display Capability	➔ Supports up to 4 monitors simultaneously
Physical Dimensions	➔ 300.2 x 142.75 x 59.2 mm (11.81" x 5.6" x 2.33")
Form Factor Width	➔ 2.96-Slot Build Layout

Connectivity & Power Pipeline

➤ DisplayPort 2.1 Outputs: Outfitted with 3 x native DisplayPort 2.1 outputs featuring UHBR 13.5 technology to connect high-refresh 4K and 8K gaming displays.

➤ HDMI 2.1 Output: Includes 1 x native HDMI 2.1 port providing uncompressed multi-channel audio and massive frame pipeline passthroughs.

➤ PCIe Power Connections: Requires 2 x standard 8-pin PCIe power connectors to adequately handle electrical load stability.

➤ System Power Requirements: A minimum 600W power supply unit (PSU) is recommended for proper overall rig configuration stability.

Ecosystem & Optimization Suite

► ASUS GPU Tweak III: An intuitive performance suite to effortlessly map custom fan speed curves, monitor core metrics in real time, and manually configure clock speed thresholds.

► AMD Adrenalin Software: Grants access to premium graphical enhancements like AMD HYPR-RX, FidelityFX™ Super Resolution (FSR), and intelligent noise suppression settings.

► Auto-Extreme Manufacturing: Put together using an automated single-pass soldering system that minimizes component thermal stress, improving reliability and environmental processing standards.

Ideal For

➔ High-VRAM Next-Gen Gamers: Perfect for desktop builds geared toward playing demanding modern titles with ultra-settings enabled at 1080p or high refresh rates at 1440p.

➔ Durability-Focused PC Builders: Ideal for users targeting industrial structural strength who want an over-engineered metal shroud and long-lived component cooling setups.

➔ Content Creators & AI Testers: Great for graphic designers, video editors, and machine learning beginners who need the massive 16GB video frame buffer to handle complex project timelines or processing queues.

➔ Silent-Build Desktop Workstations: Tailor-made for home offices where quiet operation during standard computer routines is valued alongside high graphics capacity for after-hours gaming.
